END GLOW OPTIC FIBER
Name：CLEAR END GLOW OPTIC FIBER
Details
0.25MM-4MM PLASTIC END GLOW LIGHT FIBER OPTIC CABLES
DESCRIPTION
End Light Fiber consists of PMMA fiber core and fluororesin cladding. Fiber diameter ranges from 0.25mm to 3.0mm;
With strong end glow performance. Strong end light effect;
Transmits visible light, does not transmit ultraviolet and infrared rays;
No ultraviolet or infrared ray transmitted;
No ultraviolet or infrared ray transmitted;
Non-conductive, non-heat transfer;
Flexible and transparent, uniform size, smooth surface;
Excellent toughness and can be bent arbitrarily;
Excellent toughness and can be bent arbitrarily;
Safe, energy-saving, environmental protection, maintenance-free;
Long service life, wide range of use;
End light plastic optical fibers are widely used for decorative lighting such as star ceilings, chandeliers, logos, toys etc.
Long service life, wide range of use;
End light plastic optical fibers are widely used for decorative lighting such as star ceilings, chandeliers, logos, toys etc.
BASIC PROPERTIES
Fiber core material: Polymethyl methacrylate (PMMA);
Fiber core material: Polymethyl methacrylate (PMMA);
Cladding material: Fluororesin;
Appearance: Smooth, transparent;
Numeircal aperture: 0.5;
Elongation rate: ≥4;
Allowble bending radius: ≥ ten times of the fiber diameter;
Using temperature range: -40 ~ +70℃;
MODEL SPECIFICATIONS
MODEL SPECIFICATIONS
|
Model
|
Out Dia(mm)
|
Inner Dia(mm)
|
Length(m/reel)
|
Color
|
| EK-250 |
0.25
|
0.25
|
12000
|
Clear
|
|
EK-500
|
0.5
|
0.5
|
6000
|
Clear
|
|
EK-750
|
0.75
|
0.75
|
2700
|
Clear
|
|
EK-1000
|
1.0
|
1.0
|
1500
|
Clear
|
|
EK-1500
|
1.5
|
1.5
|
700
|
Clear
|
|
EK-2000
|
2.0
|
2.0
|
250
|
Clear
|
|
EK-2500
|
2.5
|
2.5
|
250
|
Clear
|
|
EK-3000
|
3.0
|
3.0
|
150
|
Clear
|
|
Remarks: We can customize the punching and straightening at different intervals according to customers' requirements.
|
||||
Application
Usually used with LED light engines, end glow fibers are well used for a variety of occasions (hotels, saunas, KTV, bars, homes, public buildings, etc.) of lighting and decoration, such as the starry sky roof ceiling, swimming pool stars, chandeliers, fiber-optic screens, corridors, hanging, to show the soft beauty of fiber optic lamps of rhyme.
pmma fiber, optical fiber, fiber optic cable, plastic optic fiber, fiber lights
